5.0 Mega-pixel 1/3"low illumination CMOS sensor;

l5.0 Mega-pixel High Definition;

lICR switches automatically, day & night whole-day monitoring;

Waterproof Index: IP67;

Auto shutter for adjust to all kinds of environment;

No delay on signal transmission;

Transmission for more than 500 meters.

(1) Sensor5.0Mega-pixel 1/3"low-illumination CMOS sensor

(2) Signal SystemAHD@5MP

(3) Min. Illumination: Color--0.01Lux @(F1.2,AGC ON), 0 Lux (IRs on);Black & White--0.001 Lux @ (F1.2,AGC ON),0 Lux（IRs on)

(4) Shutter1/50(1/60) second~ 1/10,000 second

(5) LensHigh-definition board lens 3.6mm（2.8mm /6mm optional）

(6) Day/NightIR-CUT

(7) Maximum image size2560×1920

(8) Video Output1Vp-p Composite Output(75Ω/BNC）

(9) Audio I/ONo

(10) Working Temperature-10℃-＋60℃

(11) Working Humidity10%-90% RH

(12) Working VoltageDC12V±10%

(13) IR Distance36IRs, 20-30meters;

(14) Power ConsumptionMAX 5W

(15) Case MaterialAluminium

(16) Waterproof IndexIP67

(17) Gross Weight / piece: 0.5kg
